Technical innovation of PDC cutter
The technological innovations of PDC cutters (Polycrystalline Diamond Compact Cutters) are a significant driving force behind the advancement of oil and gas drilling technologies. Below is a detailed introduction to the technological innovations of PDC cutters.
I. Material Innovation
1.Innovation in Diamond Micropowder and Binder:
- By optimizing the particle size distribution of diamond micropowder and the formulation of binders, the hardness and wear resistance of PDC cutters have been improved.
- Some innovative technologies also employ multi-modal distributed diamond micropowder to enhance the packing density and overall performance of the polycrystalline diamond layer.
2.Design of Functionally Gradient Transition Layer:
- A material transition layer is set between the polycrystalline diamond layer and the tungsten carbide substrate to achieve a gradual transition in physical properties between the two phases.
- This design addresses the “delamination” failure issue of the polycrystalline diamond layer and enhances the impact resistance of PDC cutters.
II. Structural Design Innovation
1.Non-Planar Cutting Tooth Design:
- New cutting tooth designs, such as shallow concave PDC teeth and saddle-shaped tooth surfaces, effectively reduce residual stresses near the interface between the two phases and strengthen the bond between the diamond and the substrate.
- New cutting tooth designs, such as shallow concave PDC teeth and saddle-shaped tooth surfaces, effectively reduce residual stresses near the interface between the two phases and strengthen the bond between the diamond and the substrate.
2.Composite Drill Bit Design:
- PDC cutters are integrated with other types of cutting elements (such as roller cone bits) to form composite drill bits.
- This design combines the advantages of different cutting elements and improves the bit’s formation adaptability and rock-breaking capability.
III. Manufacturing Process Innovation
1.High-Temperature and High-Pressure Synthesis Technology:
- Higher synthesis pressures and temperatures are employed to improve the overall performance of PDC cutters.
- Some innovative technologies even increase the synthesis pressure to above 7.5 GPa, significantly enhancing the wear resistance of PDC cutters.
2.Low-Temperature Welding Technology:
- In the manufacturing process of PDC drill bits, low-temperature welding technology is used to improve the welding strength and bottomhole thermal stability of the composite plates.
- This technology helps enhance the speed and efficiency of PDC drill bits, enabling “one-trip drilling.”
